K206
Specification & Download Purchase
Specification
  • Operating System

    Nexgo OS

  • Card Readers

    Magstripe Cards : Track 1/2/3, Bi-Directional

    Smart Cards : EMV & PBOC Approved

    Contactless Cards : 13.56MHz, ISO14443,

    Type-A/B. EMV, QPBOC Approved

  • Physical

    119mm L x 65mm W x 21mm H

    109g ( Battery Included)

  • Processor

    Cortex-M4+M0 120MHz

  • Peripheral Ports

    Type C

  • Environmental

    Operating Temperature : 0°C to 50°C

    Storage Temperature : -20°C to 60°C

    Relative Humidity : 5% to 95%(Non-Condensing)

  • Memory

    4MB FLASH+256KB RAM

  • Communication

    Bluetooth, USB

  • MTTF

    ＞ 50000 Hours

  • Display

    (128 x 64) LCD with Backlight

  • PIN Pad

    Built-in PIN Pad

  • Certifications

    PCI 6.X/EMV L1&L2/Paypass/PayWave/

    JCB/AMEX/Discover/TQM/CE/RoHS

  • Keypad

    10 Function Keys

    10 Numeric Keys

  • Battery

    3.7V, 500mAh

    USB (Optional 5V/1A Charger)
