N86
Specification & Download Purchase
Specification
  • Operating System

    Powered by Android 9.0

  • Printer

    High Speed Thermal Printer

    Paper Roll Width : 58mm, Diameter: 40mm

  • Location

    GPS, GLONASS, BeiDou

  • Physical

    194mm Lx80mm Wx68.8mm H

    420g( Battery Included)

  • Processor

    Quad-Core 1.4GHz Processor

    Security Chip

  • Card Readers

    Magstripe Cards: Track 1/2/3,

    Bi-Directional, ISO7811

    Smart Cards : EMV, PBOC Approved

    Contactless Cards: 13.56MHz, ISO14443,

    Type A/B, QPBOC Approved

  • Cameras

    Rear Camera: 2 MP, FF

    5 MP, AF with Flash(Optional)

    Front Camera: 2 MP, FF(Optional)

  • Environmental

    Operating Temperature :

    0°C to 50°C

    Storage Temperature :

    -20°C to 60°C

    Shockproof:1.5m

  • Memory

    1GB RAM + 8GB Flash

    2GB RAM + 16GB Flash(Optional)

    (Micro SD Card Supported, up to 128GB)

  • Peripheral Ports

    1 x Type-C OTG, 1 x SD3.0;

    1 x SIM + 2 x SAM,

    Or 2 x SIM+1 x SAM(Optional)

  • Audio

    Built-in Speaker

  • Accessories

    Wristband

    Docking Station

    Fingerprint Module(Built-in)

    Scanning Module(Built-in)

    Multi-function Base

  • Display

    5.0" HD (1280 x 720) Color Screen,

    Capacitive Touchscreen, Multi-Touch

  • Communication

    4G/3G/2G

    Wi-Fi, 802.11b/g/n, 2.4GHz

    BT4.2

  • Battery

    7.4V/2600mAh Equals to 3.7V/5200mAh

    7.2V/3300mAh Equals to 3.6V/6600mAh(Optional)

  • MTTF

    ＞ 50000 Hours

  • Keys

    1 Power Key, 2 Volume Keys

  • PIN Pad

    Software PIN Pad

  • Adaptor

    DC 5V/2A

  • Certifications

    CCC, CE, ATEX, IP54;

    EMV3.0, L1&L2, PBOC/QPBOC, Paypass,

    PayWave, JCB, AMEX, Discover, TQM;

    PCI6.X, UPTS 3.0
